Simple Test Manifold

140028
Simple Test Manifold
Maximum Cold working pressure 10,000 PSI / 700 bar
Stainless Steel AISI 316

Object connection : 1/2" NPT male
Hose Connection : 1/2"BSP male, 60 degree cone
Gauge Connection : 1/2" BSP acc. EN 837 female ( swivel )

The Simple Test Manifold has a Needle Valve as a Block Valve in case a inspector requires to disconnect the test hose.
And just one connection to mount a Pressure Gauge.
This manifold doesn't enables you to connect a Pressure Recorder.

Consists of:
- 1x VSM-8N-2-1 - 1/2" NPT Angled Neelde Valve - male x female
- 1x BP-8GA-SS-15K - 1/2" Gauge Connection Blind
- 1x RED-8GAF-4N-SS-10K - Adapter 1/2" BSP acc. EN 837 female swivel x 1/4" NPT male
- 1x RED-8N-4N-SS-15K - Reducer 1/2" NPT male x 1/4" NPT female
- 1x TEE-8N-SS-15K - Tee 1/2" NPT Female
- 1x DN-8N-SS-15K - Double Nipple 1/2" NPT Male
- 1x VN-8N-8G-SS-15K - Adapter 1/2" NPT male x 1/2" BSP male, 60 degree cone

This manifold doesn't come with a Pressure Gauge.
€277.00 excl tax

Simple Vacuum Manifold

140029
Vacuum Manifold
Maximum Cold working pressure 10,000 PSI / 700 bar
Stainless Steel AISI 316

Object connection : 1/2" NPT male
Hose Connection : 1/2"BSP male, 60 degree cone

The Vacuum Manifold has a Ball Valve as a Block Valve to Shut-off the Vaccum Pump and remain the vacuum in your object.

Consists of:
- 1x BVSM-8N-1-1 - 1/2" NPT Ball Valve - female x female
- 1x DN-8N-SS-15K - Double Nipple 1/2" NPT Male
- 1x VN-8N-8G-SS-15K - Adapter 1/2" NPT male x 1/2" BSP male, 60 degree cone

€186.00 excl tax

Small Breather Plug for Ø63mm Gauge

140036
Small Breather Plug for Ø63mm Gauge
For Portable Backpacker CJ Pump Indication Gauge and Backpacker Handpump Indication Gauge
Fits hole diameter Ø13mm

€5.00 excl tax

Spare O-ring for 1/2" BSP End Cap and Hose Fitting

140017
Spare O-rings for 1/2" BSP End Cap and Hose Fitting
Material: NBR-70
10 pcs
€10.00 excl tax

Spare O-ring for 1/2" BSP End Cap and Hose Fitting - FKM

140020
Spare O-rings for 1/2" BSP End Cap and Hose Fitting - FKM
Material: FKM-80
10 pcs
€17.00 excl tax

Spare O-ring for 1/2" BSPA female Connection

140018
Spare O-rings for 1/2" BSPA female Connection
Material: NBR-70
10 pcs
€10.00 excl tax
